Brand Name : Mini - Circuits
Model Number : PMA3-83LN
Certification : CE, GCF, ROHS
Place of Origin : China
MOQ : 1
Price : Negotiable
Payment Terms : T/T, Western Union,
Supply Ability : 1000pcs per month
Delivery Time : 3-5 working days after received the payment
Packaging Details : Packed in original tray firstly ,then carton, at last Bubble bag for outer packing
Packaging Type : Reel Tray Tube Tape Bag
Operating Temperature : -40°C ~ 125°C
Package / Case : WSON-8
Mounting Type : SMD/SMT
Manufacturing Date Code : 2024+
Function : Step-Down
Features
Flat gain over wideband
Low noise figure, 1.3 dB at 2 GHz
High IP3, +35 dBm at 2 GHz
High POUT, P1dB +20.7 dBm at 2 GHz and +6V
Suitable for low phase noise applications
APPLICATIONS
WiFi yWLAN
UMTS
LTE
WiMAX
S-band Radar
C-band Satcom
Description
The PMA3-83LN+ is a PHEMT based wideband, low noise MMIC amplifier with a unique combination of low noise, high IP3, and flat gain over wideband making it ideal for sensitive, high-dynamic-range receiver applications. This design operates on a single +5V or +6V supply, is well matched for 50Ω and comes in a tiny 3x3 mm 12-Lead QFN-Style package, accommodating dense circuit board layouts.
Information
Category | | |
Manufacturer | Mini-Circuits | |
Series | - | |
Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Part Status | Active | |
Frequency | 500MHz ~ 8GHz | |
P1dB | 20.7dBm | |
Gain | 19.2dB | |
Noise Figure | 2.2dB | |
RF Type | LTE, Radar, SATCOM, UMTS, WiFi, WiMAX, WLAN | |
Voltage - Supply | 5V, 6V | |
Current - Supply | 77mA | |
Test Frequency | 2GHz | |
Mounting Type | Surface Mount | |
Package / Case | 12-VQFN Exposed Pad | |
Supplier Device Package | 12-MCLP (3x3) | |
Base Product Number |
